Manufacturer series images. Check the specifications for your selected model.
UWE/IWT · Industrial Bench Scales
UWE/IWT UFM Series Bench & Platform Scales
The UWE/IWT UFM series pairs a platform scale with 2-inch-tall display digits for routine industrial weighing. B, F and L models share RS232 communication and adapter or battery power, with different platform sizes and capacity choices.
The UWE/IWT UFM series pairs a platform scale with 2-inch-tall display digits for routine industrial weighing. B, F and L models share RS232 communication and adapter or battery power, with different platform sizes and capacity choices.
- B platform: 13 × 17.7 inches.
- F platform: 16.5 × 20.5 inches.
- L platform: 19.7 × 23.6 inches.
Choose the platform size for your item or container, then select an available capacity. Compare the displayed increment for that exact model: B and F versions with the same nominal capacity can have different increments.
Selected model specifications
UFM-B30
| Communications | RS232 |
|---|---|
| Weighing units | lb, kg |
| Features | 2" tall digits, portable |
| Washdown rating | Not rated |
| Power source | AC/DC external power adapter, or battery |
| Underweigh | No |
| Capacity | 60 lb / 30 kg |
| Readability | 0.02 lb / 0.01 kg |
| Divisions | 3,000 |
| Platform size | 13" x 17.7" x 3.5" |
Readability is the displayed weight increment, not a statement of weighing accuracy.
Compare UFM models
Choose the capacity and displayed increment that fit your items and containers.
| Model | Capacity | Readability | Platform / pan | Price |
|---|---|---|---|---|
| UFM-B30 | 60 lb / 30 kg | 0.02 lb / 0.01 kg | 13" x 17.7" x 3.5" | $636.43 |
| UFM-B60 | 150 lb / 60 kg | 0.05 lb / 0.02 kg | 13" x 17.7" x 3.5" | $636.43 |
| UFM-B150 | 300 lb / 150 kg | 0.1 lb / 0.05 kg | 13" x 17.7" x 3.5" | $636.43 |
| UFM-F30 | 60 lb / 30 kg | 0.01 lb / 0.005 kg | 16.5" x 20.5" x 4.5" | $764.12 |
| UFM-F60 | 120 lb / 60 kg | 0.02 lb / 0.01 kg | 16.5" x 20.5" x 4.5" | $764.12 |
| UFM-F120 | 250 lb / 120 kg | 0.05 lb / 0.02 kg | 16.5" x 20.5" x 4.5" | $764.12 |
| UFM-F300 | 600 lb / 300 kg | 0.1 lb / 0.05 kg | 16.5" x 20.5" x 4.5" | $764.12 |
| UFM-L60 | 120 lb / 60 kg | 0.02 lb / 0.01 kg | 19.7" x 23.6" x 4.5" | $936.68 |
| UFM-L120 | 250 lb / 120 kg | 0.05 lb / 0.02 kg | 19.7" x 23.6" x 4.5" | $936.68 |
| UFM-L300 | 600 lb / 300 kg | 0.1 lb / 0.05 kg | 19.7" x 23.6" x 4.5" | $936.68 |
| UFM-L600 | 1,200 lb / 600 kg | 0.2 lb / 0.1 kg | 19.7" x 23.6" x 4.5" | $936.68 |
